If you are planning an extension, a conversion or a new residential scheme in Gravesend, Northfleet or the wider borough, the daylight requirements in Gravesham will almost certainly come into play. Daylight and sunlight, both the levels reaching neighbouring homes and the quality of light enjoyed by future occupiers, are a routine consideration when Gravesham Borough Council determines planning applications. This guide sets out the adopted policy framework, the council's design guidance, and how a properly prepared daylight and sunlight assessment can strengthen your submission.
The planning framework in Gravesham
Gravesham Borough Council is the local planning authority for the borough, which includes the riverside town of Gravesend, Northfleet and a substantial rural area running south towards the North Downs. Applications are determined against the adopted development plan and national policy.
The principal adopted document is the Gravesham Local Plan Core Strategy, adopted in September 2014 following examination by an independent planning inspector. The council is also progressing an emerging new Local Plan, which has been the subject of Regulation 18 consultation; until that plan is adopted, the 2014 Core Strategy, together with saved policies and the council's adopted guidance, remains the basis for decisions. It is therefore the document you should consult when designing your scheme.
Policy CS19 and residential amenity
The key policy for daylight and sunlight is Policy CS19 (Development and Design Principles) of the Core Strategy. CS19 requires development to be well designed and to respond positively to its context, including by protecting the amenity of existing and future occupiers. Although the policy does not fix a single numerical daylight standard, the protection of living conditions, of which daylight, sunlight, outlook and privacy form part, is central to its operation. Where a proposal would harm a neighbour's daylight or sunlight, or would deliver poorly lit internal accommodation, that conflict with CS19 weighs against the scheme.
The borough's design guidance
One feature that distinguishes Gravesham from some neighbouring authorities is the breadth of its adopted design guidance. The council has produced several Supplementary Planning Documents and guidance notes that bear on amenity and design, including:
- Design for Gravesham – Design Code SPD, which supports the implementation of Policy CS19 and sets out the council's expectations for high quality, context-sensitive design.
- Householder Extensions and Alterations Design Guide SPD, aimed at ensuring extensions are well designed and sympathetic to their surroundings, including the original house and immediate neighbours.
- Residential Layout Guidelines (SPG2), applying to new dwellings, extensions, flats, maisonettes and conversions, with the associated housing standards.
These documents reinforce the message that an extension or new building should not have an unacceptable effect on the amenity of neighbouring properties, which in practice covers loss of light and overshadowing. Reviewing the relevant SPD for your project type before you finalise a design is well worth the effort.
How daylight and sunlight are assessed
Gravesham does not publish a bespoke numerical daylight standard within its policies. Instead, the recognised national technical benchmark is applied through the Local Plan and the National Planning Policy Framework. That benchmark is the Building Research Establishment guidance, BRE BR 209 in its 2022 edition, supported by the daylight provisions of BS EN 17037.
The main BRE tests
BR 209 sets out the methods most commonly relied upon in assessing daylight and sunlight impacts:
- Vertical Sky Component (VSC) – skylight reaching a neighbouring window, with a retained value of around 27 per cent, or no more than roughly a 20 per cent reduction from the existing value, often used as a guide.
- No Sky Line / Daylight Distribution – how far daylight penetrates a room, indicating whether part of a room becomes noticeably darker.
- Annual Probable Sunlight Hours (APSH) – sunlight reaching windows facing within 90 degrees of due south, relevant to living rooms and to gardens and amenity spaces.
Crucially, BR 209 describes its figures as guidelines to be applied with judgement, not as fixed thresholds. In the more tightly developed parts of Gravesend town centre, and in higher density riverside regeneration, somewhat lower retained values may be acceptable where the analysis is robust and the context justifies it. In the lower density suburban streets and the rural fringe near the North Downs, more generous standards are usually expected.
Local context worth keeping in mind
Two local factors often shape daylight outcomes in Gravesham. First, Gravesend is a historic riverside town on the Thames with a compact, mixed character town centre, where tighter plot relationships and taller buildings make daylight and sunlight a sensitive issue for both neighbours and new occupiers. Second, the borough has an extensive design guidance suite, so officers will expect proposals to engage with the relevant SPD and to demonstrate that amenity, including light, has been properly considered. Bringing the two together, a scheme that aligns with the design code and is backed by a clear BRE assessment tends to progress more smoothly.
Practical tips for applicants
- Read Policy CS19 and the relevant SPD, either the Design for Gravesham Design Code or the Householder Extensions and Alterations Design Guide, before finalising your design.
- Identify neighbouring windows, gardens and amenity areas that could be affected, and consider light early in the design process.
- Where impacts are likely, commission a daylight and sunlight assessment to BRE BR 209 (2022) to evidence the position transparently.
- Consider pre-application advice for larger or more sensitive proposals.
How Fortress Associates can help
Fortress Associates provides our daylight and sunlight report service to BRE BR 209 (2022), BS EN 17037 and the relevant Local Plan, prepared to support planning applications in Gravesham and across the UK. We also produce Building Regulations drawings. We work nationwide with a 4 to 5 working day turnaround and ask for no advance payment. See our services or contact us to discuss your project. If your site is nearby, our guide to daylight requirements in Dartford may also be helpful.
