Understanding the daylight requirements in Vale of Glamorgan is essential for anyone planning a house extension, infill plot or larger residential scheme in Barry, Penarth, Cowbridge or the surrounding villages. The council (Cyngor Bro Morgannwg) assesses how a proposal affects light to neighbouring homes through its adopted development plan and supporting design guidance, supported where appropriate by a technical daylight and sunlight report. This article sets out the local policy position and how it is applied in practice.
The planning framework in the Vale of Glamorgan
Daylight in the Vale of Glamorgan is governed by the Vale of Glamorgan Local Development Plan 2011-2026, which the council adopted on 28 June 2017. The LDP is the statutory starting point for decisions on planning applications, and it sits within the wider Welsh planning framework rather than the English system.
That wider framework comprises Planning Policy Wales (Edition 12, 2024), Future Wales: the National Plan 2040, and the relevant Technical Advice Notes (TANs). Planning Policy Wales places strong emphasis on good placemaking and on protecting residential amenity, which includes adequate levels of daylight and sunlight for both existing and future occupiers. The Vale is also preparing a Replacement LDP (2021-2036), but until that is adopted the 2011-2026 plan remains the development plan in force.
Key adopted LDP policies
Two policies in the adopted LDP are central to daylight and amenity matters:
- Policy MD2 - Design of New Development. This is the principal design policy. Criterion 8 requires development to "safeguard existing public and residential amenity, particularly with regard to privacy, overlooking, security, noise and disturbance". Criterion 2 requires proposals to respond appropriately to the local context and character of neighbouring buildings in terms of scale, form and density - factors that directly influence overshadowing.
- Policy SP1 - Delivering the Strategy. This strategic policy confirms the plan's aim to improve the living and working environment and to protect and enhance the built environment, providing the high-level justification for amenity protection across the Vale.
Other policies such as MD5 (Development within Settlement Boundaries) and MD8 (Historic Environment) may also be relevant depending on the site, particularly in the conservation areas of Cowbridge and Penarth.
The Residential and Householder Development SPG
The detail behind Policy MD2 is set out in the council's adopted Residential and Householder Development Supplementary Planning Guidance (2018). This is the document Vale of Glamorgan case officers rely on most heavily when judging the daylight impact of an extension or new dwelling, and it is unusually specific.
Daylight, sunlight and overshadowing
Section 9 of the SPG, headed "Impact on Neighbours", states that development which "results in a significant loss of daylight and/or sunlight to habitable rooms (i.e. living room, main bedroom, kitchen and dining room) or private garden areas of neighbouring properties" is likely to be harmful. The guidance defines a habitable room as one in which occupiers spend a significant amount of time - bedrooms, living rooms, dining rooms and kitchens - and asks applicants to consider the orientation of development relative to the sun to minimise overshadowing.
The 21-metre separation distance
A distinctive local design standard in the Vale is the privacy separation rule. The SPG sets a minimum distance of 21 metres between opposing windows in habitable rooms. Where there is a difference in ground levels, the distance is measured horizontally between the properties. Habitable-room windows that directly overlook a neighbour's garden in close proximity to boundaries are treated as likely to be harmful, and reduced separation may be acceptable only where windows are set at an angle or obscure-glazed.
When a daylight and sunlight report is needed
The SPG confirms that a Sunlight / Daylighting Assessment is applicable to "all applications where there is a potential adverse impact upon the current levels of sunlight/daylighting enjoyed by adjoining properties and buildings", and it directs applicants to the Building Research Establishment's guidelines on daylighting assessments. For roof lights and loft conversions the guidance notes the council may request daylight factors to justify the need and size of an opening.
How daylight and sunlight are measured
Although Vale of Glamorgan policy sets the local tests, the technical methodology applied across Wales and the rest of the UK is the Building Research Establishment guide BRE BR 209: Site layout planning for daylight and sunlight (2022, third edition). A professional assessment will typically address:
- Vertical Sky Component (VSC) - light reaching a neighbouring window, with the familiar guideline that retained VSC should not fall below 0.8 times its former value.
- No Sky Line / daylight distribution - the proportion of a room that can still see the sky.
- Annual Probable Sunlight Hours (APSH) - sunlight to windows with a southerly aspect.
- Internal daylight for new rooms, assessed against the recommendations of BS EN 17037 (Daylight in Buildings).
These numerical results give the council an objective basis for applying the qualitative "significant loss" test in the SPG and the amenity requirements of Policy MD2.
Local context across the Vale
The Vale's settlements present very different daylight challenges. In Barry, the council has produced specific guidance including the Barry Development Guidelines SPG and the Barry Garden Suburb SPG, reflecting the scale of regeneration around the waterfront. In the historic core of Cowbridge and the Victorian streets of Penarth, tight plot widths and conservation-area character mean that even modest extensions can raise overshadowing and overlooking concerns. A clear, BRE-based assessment is often the most effective way to demonstrate that a scheme respects the 21-metre rule and the daylight tests in the SPG.
How Fortress Associates can help
Fortress Associates prepares our daylight and sunlight report service to BRE BR 209 (2022) and BS EN 17037, tailored to the Vale of Glamorgan's adopted LDP and Residential and Householder SPG. We also produce Building Regulations drawings where a project is proceeding to construction. We work UK-wide with a 4-5 working day turnaround and no advance payment required. To discuss a Barry, Penarth or Cowbridge scheme, get in touch or see our guide to daylight requirements in Wrexham.
